Brother CS6000i LCD Screen Replacement

Written By: Wasim Benbrahim
  • Comments: 0
Brother CS6000i LCD Screen Replacement

Difficulty

Easy

Steps

5

Time Required

10 - 20 minutes

Introduction

This guide will be showing you how to replace the LCD screen on a Brother CS6000i sewing machine. The LCD screen helps the user identify what sewing mode and speed they are working with. Some common symptoms particularly related to a faulty LCD screen would be faulty diodes or a blank screen while the machine is in operation.

Before beginning make sure power is disconnected and needle is removed from machine to prevent injury from electrical shock and or sharp objects.

  1. gHBCqmQxl1xlTgNJ
    gHBCqmQxl1xlTgNJ
    4brVwmOqhKKA2aEh

    • Remove the five 20 mm Phillips #2 screws on the back of the device.

    • Remove the single 28 mm Phillips #2 screw on the back of the device.

    • Remove the single 23 mm Phillips #2 screw on the back of the device.

  2. khTF4unDjLUHG6BN
    khTF4unDjLUHG6BN
    2bMLWSYLw5hesvYu

    • Pull the white cover off.

  3. OGYPMEXYdaphgvaY
    OGYPMEXYdaphgvaY
    12Gjhy3HEOKUDOxC

    • Remove the final screw, a 11 mm Phillips #2.

    • After removing all eight screws, you will have five 2 mm screws, one 28 mm screw, one 23 mm screw, and one 11 mm screw, all of which are Phillips #2.

  4. e4rhLwRchXLjZdDZ
    e4rhLwRchXLjZdDZ
    hHiGEOVBCiCa2NCm
    CB63ku3eqSjJwsf6

    • Slightly pull apart the two halves of the machine, taking care not to strain the attached cables.

    • Unhook the white wires that are connected to the motherboard.

    • Fully separate the two halves.

  5. JV3Qs5b5PaRKHKEH

    • Remove the two 10 mm Philips #2 screws that secure the screen.

    • Unplug the ribbon cable located at the top of the circuit board, then gently remove the LCD screen.

Conclusion

To reassemble your device, follow these instructions in reverse order.
